CHIPSET | INTEL B760 |
CPU | Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors |
| LGA 1700 |
MEMORY | 4x DDR5, Maximum Memory Capacity 192GB |
| Memory Support DDR5 6800+(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz |
| Max. overclocking frequency: |
| • 1DPC 1R Max speed up to 6800+ MHz |
| • 1DPC 2R Max speed up to 6400+ MHz |
| • 2DPC 1R Max speed up to 6000+ MHz |
| • 2DPC 2R Max speed up to 5600+ MHz |
| |
| Supports Intel® XMP 3.0 OC |
| Supports Dual-Controller Dual-Channel mode |
| Supports non-ECC, un-buffered memory |
SLOT | 5x PCI-E x16 slot |
| PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU) |
| PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) |
| PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) |
| PCI_E4 Gen PCIe 3.0 supports up to x1 (From Chipset) |
| PCI_E5 Gen PCIe 3.0 supports up to x1 (From Chipset) |
STORAGE | 2x M.2 |
| M.2_1 Source (From CPU) supports up to PCIe 4.0 x4, supports 22110/2280/2260/2242 devices |
| M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices |
| 4x SATA 6G |
| * SATA8 will be unavailable when installing M.2 SATA SSD in the M2_2 slot. |
RAID | Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices |
USB | 4x USB 2.0 (Rear) |
| 4x USB 2.0 (Front) |
| 2x USB 3.2 Gen1 Type A (Front) |
| 1x USB 3.2 Gen1 Type C (Front) |
| 2x USB 3.2 Gen2 Type A (Rear) |
| 1x USB 3.2 Gen2 Type C (Rear) |
LAN | Realtek® RTL8125BG 2.5G LAN |
WIRELESS LAN & BLUETOOTH | Intel® Wi-Fi 5 |
| Supports 802.11 a/b/g/n/ac, MU-MIMO Rx, 2.4GHz/ 5GHz up to 433 Mbps |
| Supports Bluetooth® 5.1 |
AUDIO | Realtek® ALC897 Codec |
| 7.1-Channel High Definition Audio |
| Supports S/PDIF output |
INTERNAL IO | 1x Power Connector(ATX_PWR) |
| 2x Power Connector(CPU_PWR) |
| 1x CPU Fan |
| 1x Pump Fan |
| 5x System Fan |
| 2x Front Panel (JFP) |
| 1x Chassis Intrusion (JCI) |
| 1x Front Audio (JAUD) |
| 1x Printer Port (JLPT) |
| 1x Com Port (JCOM) |
| 1x TBT connector (JTBT, supports RTD3) |
| 2x Addressable V2 RGB LED connector (JARGB_V2) |
| 1x RGB LED connector(JRGB) |
| 1x TPM pin header(Support TPM 2.0) |
| 4x USB 2.0 ports |
| 2x USB 3.2 Gen1 Type A ports |
| 1x USB 3.2 Gen1 Type C ports |
LED FEATURE | 4x EZ Debug LED |
BACK PANEL PORTS | Keyboard / Mouse |
| 2.5G LAN |
| USB 2.0 |
| Wi-Fi / Bluetooth |
| Audio Connectors |
| USB 2.0 |
| USB 3.2 Gen 2 10Gbps (Type-A) |
| USB 3.2 Gen 2 10Gbps (Type-C) |
| S/PDIF-OUT |
OPERATING SYSTEM | Support for Windows® 11 64-bit, Windows® 10 64-bit |
PCB INFO | ATX |
| 243.84mmx304.8mm |
